130V 1.1A plug-in self recovery fuse model and specifications.autozone fuse tap

　　We usually use 16V, 30V, 60V, 72V, 240V, 250V, 600V plug-in self recovery fuses, while 130V plug-in self recovery fuses are relatively special. There are two size specifications for the 130V 1.1A plug-in self recovery fuse. One specification is a regular straight foot size with a chip diameter of 16.3mm, a thickness of 3.8mm, a foot pitch of 5.1mm, and a foot length of 8-12mm. The other specification is a curved foot small size with a chip diameter of 12.8mm, a thickness of 3.8mm, and a foot pitch of 5.1mm, and a foot length of 8-12mm. There are two different sizes of 130V 1.1A plug-in fuses, and their main parameters also differ. The rated current of the conventional size 130V 1.1A plug-in self recovery fuse is 1.1A, the fusing current is 2.2A, the maximum voltage is 130V, and the maximum current is 10A. The small-sized 130V 1.1A plug-in self recovery fuse has a rated current of 1.1a, a fusing current of 2.2 Ah, a maximum voltage of 130V, and a maximum current of 10A. The production materials for this model are: pins,: tinned copper clad steel wire; Packaging material: Flame retardant epoxy resin polymer; Solder, environmentally friendly solder.

　　The 130V 1.1A plug-in self recovery fuse has the same purpose and characteristics in both sizes, and is suitable for load protection on various low-voltage power sources, computers, computer peripherals, general electronics, and other fields. The normal working environment for the self recovery fuse of 130V 1.1A plug-in is -40 ℃ -+85 ℃. The packaging method is in bags, with 500pcs in one bag.
