250V 1.2A plug-in fuse A250-1200.resettable fuse smd

15

2023-08

Share:

　　6473e15196746dc

　　The commonly used series of plug-in fuses include A16, A30, A60, A72, A240, A250, A600, which belong to plug-in recoverable fuses. The maximum voltage of the A250 series plug-in fuse is 250V, and the commonly used current range of this series is 0.03A-1A. Today we will learn about the 1.2A fuse part number of the 250V series plug-in fuse type.

　　250V 1.2A plug-in fuse, the corresponding model of the brand is A250-1200. The holding current of this material number is 1.2A, the triggering current is 2.4A, the maximum voltage range is 220V~250V, and the maximum current is 5A. When the current passing through the fuse reaches the classic current value of 6A, the fuse will operate within 15 seconds. The power Pdtyp generated during the action of this material number is 5W, with a minimum resistance Rmin of 0.17 Ω, a maximum resistance Rmax of 0.28 Ω, and a maximum resistance R1max of 0.5 Ω after the first action.

　　The dimensions of the A250-120 plug-in fuse are: width A: 16.7mm, height B: 20.5mm, foot length D: 7.6mm, foot distance C: 5.1mm, thickness E: 4.1mm, and pin diameter 0.8mm.home energy storage system battery

　　The operating temperature range of the A250-120 plug-in fuse is -40 ℃~+85 ℃. The material details of the product are as follows: the pins are tinned copper clad steel wires, the packaging material is flame-retardant epoxy resin polymer, the solder is environmentally friendly solder, and the materials used comply with RoHS requirements.
