　　Plug-in fuse

　　The plug-in fuse can be divided into: ultra small plug-in fuse, small car fuse, medium car fuse, and large car fuse.

　　The rated current ranges from 1-40 amperes (A) to larger sizes of 30-120 amperes (A), and the rated voltage is 32 volts (V).

　　Fork bolt fuse

　　The fork bolt type fuse can be divided into: small fork bolt type fuse and large fork bolt type fuse.

　　The rated current ranges from 30-150 amperes (A) to large sizes of 40-800 amperes (A), and the rated voltage is 32/125 volts (V).

　　Car glass tube fuse

　　Car glass tube fuse can be divided into: 6.35 × 30mm glass tube fuse, 6.35 × 31.75mm glass tube fuse, 10 × 38mm glass tube fuse.

　　The rated current ranges from 0.5 to 20 amperes (A) to 10 × 38mm20-80 amperes (A), rated voltage 32 volts (V).
