　　According to size, it can be divided into

　　Dimensions, 3.6X10, 3X10, 5X20, 6X30, 6X32, 6X25, 10 * 38, 2.4X7, 2.5X6, 3X8, 2.5X9, 8.5X8, 8.5X8X4, 3.5X10, 3.5X9

　　According to current, it can be divided into

　　32ma, 63ma, 100mA, 150mA, 200mA, 250mA, 300mA, 400mA, 500mA, 600mA, 800mA, 1A, 1.25A, 1.6A, 2A, 2.5A, 3A, 3.5A, 4A,

　　5A, 6A, 7A, 8A, 9A, 10A, 12A, 15A, 20A, 25A, 30A

　　According to material classification, it can be divided into

　　Glass current fuse, ceramic current fuse
