　　1. Carefully select the correct current fuse

　　The application, operating parameters, and environment of fuses can all affect their lifespan, so choosing the correct fuse is very important.

　　2. Ensure the rationality of circuit design

　　Faults in circuit design can also lead to fuse failure, which can be catastrophic. Only by ensuring that the equipment operates within a larger rated range can faults be avoided.

　　3. Reasonable use of fuses

　　Correct use can avoid faults caused by errors, and it is also important to control the ambient temperature of the fuse used, which helps to reduce the possibility of current fuse holder failure. If you are unfamiliar with the use of fuses, you can directly consult the fuse manufacturer.
