Resistive Type 251 Quick Break Fuse.smd fuse letter codes

16

2023-08

Share:

　　bbfb9e10b592b37

　　The appearance dimensions of the 251 series fuses are available in multiple models: 2 * 6mm, 2.4 * 7mm, 3 * 9mm, and 2.5 * 6mm.

　　251 series axial lead fuse, size 2.4 × 7mm, small in size, suitable for various small electrical appliances.

　　The rated voltage range is 125V~250V, and the rated current range is 125mA~6.3A.

　　The appearance of the 251 series resistive fuses is composed of brass nickel plated copper caps and leads, ceramic tubes, etc. The product body colors are green and yellow, among which the appearance of 2 * 6mm and 3 * 9mm resistive fuses is marked with a color ring to distinguish the size of the current. It is a special fast break fuse.

　　The 251 series resistive fuses have a wide range of applications in the industry and circuits, and can be used in current supplies, switching power supplies, computers, chargers, telephones, household appliances, communication products, various instruments and electronic components, motor products, and various small household appliances.

　　The above are the relevant features of the 251 resistive fuse and its application range. If there are any other questions that you do not understand or if it is difficult to select, please consult an online salesperson or technical engineer to analyze product performance and solve product selection problems.
