air conditioner fuse box replacement..Application scope of patch self recovery insurance

11

2023-11

Share:

　　d83bbc296c1f220

　　Self recovery fuses can be divided into patch based self recovery fuses and plug-in self recovery fuses. With the increasing miniaturization of product requirements, the range of use of patch based fuses has increased.

　　The main encapsulation of SMD self recovery fuses are: 0805, 0603, 1206, 1812, 2920, and their working principle is:home energy storage system battery

　　The self recovery fuse is composed of specially treated polymer resin and conductive particles (Carbon Black) distributed inside. Under normal operation, the polymer resin tightly binds conductive particles outside the crystalline structure, forming a chain like conductive electrical pathway. At this time, the recoverable fuse is in a low resistance state (a), and the heat generated by the current flowing through the self recovering fuse on the circuit is small and does not change the crystal structure. When a circuit experiences a short circuit or overload, the heat generated by the large current flowing through the self recovery fuse causes the polymer resin to melt, rapidly increase in volume, and form a high resistance state (b). The working current rapidly decreases, thereby limiting and protecting the circuit. After the fault is eliminated, PTC can restore the fuse to cool and crystallize again, shrink the volume, and the conductive particles form a conductive path again. The self restoring fuse returns to a low resistance state, thus completing the protection of the circuit without the need for manual replacement.

　　Application scope

　　Communication equipment: program-controlled switches, user terminal equipment, main wiring security units, etc.

　　Automotive electronics: automotive wiring harnesses, automotive anti-theft devices, automotive micro motors, automotive electronic products, etc.

　　Electronics industry: power ballasts, micro motors, fire alarms, instruments and meters, etc.

　　Electrical equipment: satellite receivers, security equipment, speakers, industrial automatic control, etc.
