　　Each type of circuit protection component has specifications, and self recovery fuses are no exception. So, what do you think when holding a self-healing fuse specification book? To put it bluntly, when reading the specifications, the main focus is on the parameters and the meanings they represent:

　　I hold: Maintain current

　　I trip: The maximum action time under the specified current;

　　V max: Maximum voltage that can be withstood

　　I max: Maximum current that can be withstood

　　P d: Stable power consumption in high resistance state

　　R: Zero power resistance measured at a certain temperature

　　R 1max: The maximum resistance value measured at room temperature after one hour of action or soldering back

　　Environmental temperature: The temperature of the still air around PTC

　　Maximum working environment temperature: The highest ambient temperature for PTC safe operation
