motor thermostat wiring diagram.What is the structure of the fuse?

　　A general fuse consists of three parts: the first is the melt part, which is the core of the fuse and plays a role in cutting off the current when fused. Fuses of the same type and specification in Shenzhen should have the same material, geometric size, and resistance value as small and consistent as possible. It is important to have consistent fusing characteristics; The second is the electrode part, which usually has two important components that connect the melt to the circuit. It must have good conductivity and should not generate obvious installation contact resistance; The third part is the support part, where the melt of the fuse is generally thin and soft. The function of the support is to fix the melt and make the three parts a rigid whole for easy installation and use. It must have good mechanical strength, insulation, heat resistance, and flame retardancy, and should not produce phenomena such as breakage, deformation, combustion, and short circuit during use;

　　The fuses used in power circuits and high-power equipment not only have the three parts of a general fuse, but also have arc extinguishing devices. This type of fuse not only protects the circuit with a high working current, but also has a high voltage at both ends when the melt melts. Often, the melt has melted (melted) or even vaporized, but the current is not cut off, The reason is that at the moment of fusing, under the action of voltage and current, an arc pulling phenomenon occurs between the two electrodes of the fuse. This arc extinguishing device must have strong insulation and good thermal conductivity, and be negatively charged. Quartz sand is a commonly used arc extinguishing material.

　　In addition, some fuses have a blown indicator device, which is used to indicate that when the fuse is activated (blown), its appearance changes to a certain extent, making it easy for maintenance personnel to detect, such as emitting light, discoloring, and popping up solid indicators.
