motorcycle fuse block with relay.Self recovery fuse parameters

19

2023-10

Share:

　　4a1b04abe13c78

　　IH: Maximum working current (25 ℃)

　　IT: Minimum operating current (25 ℃)

　　Itrip: Overload current

　　Tmax: Maximum action time of overload current

　　Vmax: Maximum overload voltage

　　Imax: Maximum overload current

　　Rmin: minimum resistance (25 ℃)

　　Rmax: Maximum resistance (25 ℃)

　　Self recovery fuse application

　　The self recovery fuse is connected in series in the DC/AC power circuit. DIP direct insertion or SMD surface mount can be selected PPTC has no positive or negative polarity. As PPTC is in a protected state and has a high surface temperature, it should be installed in a ventilated state. High temperature sensitive components should not come into direct contact with PPTC

　　Application scope:

　　Application of Self Recovery Fuses in ADSL Devices

　　Application of Self Recovery Fuses in Radio Products, Battery Packs, and Charger Products Overcurrent Protection in Automotive Electronics and Components

　　Application of remote control electric toy cars, high-frequency and low-frequency power chargers in electronic toys such as electric toys and baby strollers

　　Application of Satellite Receiver DVB Products

　　The Application of Self Recovery Fuses in Communication Terminal Equipment Products

　　Application in Power Supply Products

　　Home Theater/Speaker/Divider/Electromagnetic Load/Motor/Vacuum Cleaner
