　　The 0467 series patch fuse is a disposable fuse, and the fast melting surface mount fuse (SMF) is a ultra small (0603 size) thin film device designed for secondary protection of circuits used in space limited applications such as handheld portable electronic devices. This series is 100% lead-free and meets the requirements of the RoHS directive.

　　The rated current range of the 0467 series patch fuse is 0.25A-5A, the rated voltage is 32V, the working environment temperature is -55 ℃ to 125 ℃, the cold resistance is 0.0089-0.5650, and the voltage drop is 61.20-158.56. The main material of this series: The fuse body is mainly an advanced high-temperature substrate, with 100% tin nickel on copper at both ends and a conformal coating on the outer layer. This series works normally in an environment of -55 ℃~90 ℃, with a specification size of 1.6mm * 0.8mm and packaging method of 8mm mm tape and reel, with 5000 pieces per roll.

　　0467 Chip Fuse Parameter Table

　　The 0467 series fuse models of Kedi include:

　　0467.250, 0467.375, 0467.500, 0467.750, 0467.001., 0467.125, 0467.015, 0467.175, 0467.002., 0467.025, 0467.003, 0467.035, 0467.004, 0467.005.
